Pilz solutions package to safeguard automated guided vehicle systems

By OEM Update Editorial December 13, 2022 12:21 pm IST

The package comprises safety and security for the comprehensive safeguarding of an automated guided vehicle system. It is one-stop safety and security for mobile applications –whether track-bound or freely navigating AGVS.
The automation expert Pilz offers manufacturers a new solution package to safeguard automated guided vehicle systems (AGVS), comprising safety and security. With the complete solution containing safe area monitoring for collision protection for humans and AGVS, plus safe evaluation units and tamper protection, Pilz offers one-stop safety and security for mobile applications –whether for track-bound or freely navigating AGVS.
The complete solution includes the safety laser scanners PSENscan (collision protection for humans and AGVS), the modular safety relay myPNOZ and the small configurable controller PNOZmulti 2 (as evaluation units), plus the industrial firewall SecurityBridge (tamper protection).
Various control and signal devices, such as the evaluation unit from the operating mode selection and access permission system PITmode fusion, PITreader, the E-STOP pushbutton PITestop and the muting lamps PITsign, complete an efficient monitoring package for users.
Don’t give tampering the green light

The complete Pilz solution covers tamper protection on mobile applications for the first time. The integrated security solution via the firewall Security Bridge protects automated guided vehicles or vehicle systems from unauthorised access during wireless communication. It reliably ensures that no one can access the internal IT network of the mobile platform without authorisation during operation. As such, the AGVS and its map data remain protected, and productivity is guaranteed.
Safe scanner technology points the way.
Within the solution package, the safety laser scanner PSENscan enables mobile platform safeguarding and productive area monitoring. On track-bound AGVS, PSENscan detects objects along the route, even at high speeds, and adjusts warning and safety zones in a functionally safe manner. PSENscan provides up to 70 protected fields. These enable dynamic protected field adjustment, even on freely navigating AGVS. ROS packages (open-source robot operating system) for the PSENscan provide the data for the dynamic navigation of AGVS. Users can apply these for their SLAM algorithm (Simultaneous Localisation and Mapping).
Flexible, mobile control
Suppose additional safety functions are to be covered on the AGVS, such as E-STOP. In that case, users can apply a flexible product solution comprising PSENscan and the modular safety relay myPNOZ. Should requirements change, myPNOZ can be expanded to suit any future addition to the function range. That enables a high degree of flexibility when designing mobile applications.
With the configurable small controller PNOZmulti 2 with motion monitoring module, Pilz also offers an efficient and flexible solution for more complex protected field adjustments on freely navigating AGVS.
